DM002 DIY WiFi FPV Quadcopter Drone Kit with 6-Axis Gyro (Without Camera)

(0 review)
SpecificationDetails
Drone TypeFoldable RC FPV Quadcopter
Camera ResolutionNo Camera
Motor TypeCoreless Motor
Battery ConfigurationSingle Modular Battery Pack
Flight TimeApprox. 8–12 Minutes
ConnectivityWiFi FPV + App Control
Price
₹ 1,822.03 ₹ 1,822.03 ₹ 2,499.00
(Tax included)

बारकोड: 37810

Product Description

The DM002 is more than just a toy; it is a STEM learning platform. The open-frame design allows you to see how the flight controller communicates with the four coreless motors. It features three speed modes, making it easy for beginners to start slow and increase agility as they gain confidence. The drone is capable of performing 360° flips and includes a "One-Key Return" function to assist with navigation.

Key Features

  • DIY Assembly: Provides a hands-on building experience that teaches the inner workings of quadcopter electronics and frame mechanics.

  • WiFi FPV Feed: Streams live video to your phone, allowing you to fly from the drone's perspective and capture basic aerial photos/videos.

  • Stable Flight Performance: The 6-axis gyro ensures smooth hovering and precise control, even for first-time pilots.

  • Modular Parts: All components—from motors to the frame—are easily replaceable, making repairs after a crash simple and inexpensive.

  • High-Visibility LEDs: Features bright, colorful LED lights for orientation during day flights and enhanced visibility during night flying.

Technical Details

  • Motor Type: 7mm x 20mm Coreless Motors.

  • Frame Material: Lightweight and resilient ABS plastic.

  • Smartphone Support: Compatible with "idrones wifi" or similar apps for FPV viewing.

Prototyping and Engineering Tips from Robogears

  • Motor Orientation: Pay close attention to the wire colors. The red and blue wire motors are for clockwise rotation, while black and white are for anti-clockwise. Swapping these will prevent the drone from taking off.

  • Extend Your Flight: To get the longest flight time possible (up to 15 minutes), you can disconnect the WiFi camera module when you are just practicing your piloting skills, as the camera transmitter consumes significant power.

  • Antenna Positioning: Ensure the small copper antenna on the flight controller is pointing slightly upward and is not blocked by the battery or wires to maintain the best possible signal range.

  • Propeller Prep: Use the included Props Pulling Helper (wrench) to remove propellers. Prying them off with your fingers can bend the thin motor shafts, leading to unwanted vibrations and unstable flight.

Package Includes

  • 1 x DM002 Main Frame & Protective Case

  • 1 x 2.4G Transmitter (Remote Control)

  • 1 x Flight Controller Board

  • 1 x WiFi FPV Camera Module

  • 4 x Coreless Motors (2x CW, 2x CCW)

  • 8 x Propellers (Full set + Spares)

  • 1 x 3.7V 300mAh Li-Po Battery & USB Charger

  • 1 x Assembly Manual & Propeller Wrench

Disclaimer

This is a DIY kit that requires manual assembly. Ensure all motor wires are tucked into the frame slots to prevent them from being cut by the spinning propellers during flight.
