802540P 3.7V 600mAh Li-Po Rechargeable Battery | JST Plug | Compatible with RC Drone, Helicopter, Boat, Car, LED, Arduino & DIY STEM Projects

802540P 3.7V 600mAh Li-Po Rechargeable Battery | JST Plug | Compatible with RC Drone, Helicopter, Boat, Car, LED, Arduino & DIY STEM Projects

(0 review)
ComponentSpecification
ChemistryLithium Polymer (Li-Po)
Model Code802540P (8.0mm x 25mm x 40mm)
Nominal Voltage3.7V
Full Charge Voltage4.2V
Capacity600mAh
Connector TypeJST-PH 2.0 / Standard RC Plug
WeightApprox. 12g to 15g
Price
₹ 250.00 ₹ 250.00
(Tax included)

Product Description The 802540P 600mAh Li-Po battery is a lightweight, high-energy-density power source designed for small-scale electronics and RC vehicles. With its compact "pouch" form factor, it provides a superior power-to-weight ratio, making it an ideal choice for micro drones, small quadcopters, and portable STEM projects. The pre-installed JST connector ensures a secure and polarized connection, while the integrated protection circuit (in most batches) helps safeguard the cell during standard operation.

Key Features

  • Compact & Lightweight: Optimized for flight and mobile applications where every gram counts.

  • High Discharge Capability: Engineered to provide the burst current necessary for RC motors and servos.

  • Standard JST Connector: Plug-and-play compatibility with most micro RC receivers and flight controllers.

  • Stable Energy Output: Delivers a consistent 3.7V nominal voltage for reliable electronics performance.

  • Versatile Application: Fits perfectly into DIY wearable tech, wireless sensors, and small-scale robotics.

Technical Details

  • Dimensions: 8.0 mm (Thickness) x 25 mm (Width) x 40 mm (Length)

  • Standard Charge Rate: 0.5C (300mA)

  • Max Charge Voltage: 4.25V

  • Discharge Cut-off Voltage: 3.0V

  • Operating Temperature: -20°C to +60°C

  • Internal Protection: Over-charge, over-discharge, and short-circuit protection (Check specific batch)

Prototyping and Engineering Tips from Robogears

  • Charging Safety: Always use a dedicated Li-Po balance charger. Never charge Li-Po batteries with a standard DC power supply, as overcharging can cause the battery to swell or ignite.

  • The "Puff" Test: If you notice the battery casing starting to "puff" or swell, discontinue use immediately. This is a sign of internal chemical degradation or previous over-discharge.

  • Connector Polarity: While the JST plug is polarized, always verify that the Red (Positive) and Black (Negative) wires match the pinout of your device. Some manufacturers may use a reversed polarity on specific flight controllers.

  • Storage Charge: If you don't plan to use the battery for more than a week, discharge or charge it to approximately 3.8V (storage voltage). Storing a Li-Po at full charge (4.2V) or complete discharge (3.0V) for long periods will significantly reduce its lifespan.

Package Includes

  • 1 x 3.7V 600mAh Li-Po Rechargeable Battery (802540P)

Disclaimer Images are for reference; actual labeling or wire length may vary. Specifications subject to change by manufacturer. Handle with extreme care; do not puncture, crush, or expose to high temperatures.
