8-Pin Flat Dial Rotary DIP Switch 2.54mm

Specification	Details
Switch Type	Flat Dial Rotary DIP Switch
Number of Pins	8 Pins
Pin Pitch	2.54mm
Mounting Type	Through Hole PCB Mount
Configuration Type	Rotary Address Selection
Application	Electronic Circuit Configuration

Price

₹ 29.66

(Tax included)

Barcode: 901304

The 8-Pin Flat Dial Switch 2.54mm is a compact rotary DIP switch designed for selecting addresses, modes, and configuration settings in electronic circuits. With a standard 2.54mm pin spacing and easy-to-rotate dial mechanism, it provides a reliable and space-efficient solution for embedded systems, industrial controllers, communication devices, and DIY electronics projects.

Key Features:

Rotary Dial Selection allows quick and accurate configuration of circuit settings.
Standard 2.54mm Pin Pitch ensures compatibility with common PCB layouts and prototyping boards.
Compact Flat Design makes it suitable for space-constrained electronic devices.
Reliable Through-Hole Mounting provides secure PCB installation and long-term durability.
Ideal for Address Selection in microcontroller, communication, and industrial control applications.

Technical Details:

Product Type: Rotary DIP Switch
Number of Pins: 8
Pin Pitch: 2.54mm
Mounting Type: Through Hole
Switch Style: Flat Dial
Configuration Method: Rotary Selection
Operating Current: Approx. 0.15A
Compact PCB Design: Yes
Suitable Applications:
- Address Selection Circuits
- Embedded Systems
- Industrial Controllers
- Communication Equipment
- Automation Projects
- DIY Electronics Prototyping

Prototyping and Engineering Tips from Robogears:

Use the dial switch for selecting device addresses or operating modes without requiring firmware modification.
Ensure the dial is fully aligned with the desired position to prevent incorrect circuit configuration.
When soldering, avoid excessive heat on the pins to maintain switch reliability and smooth operation.

Package Includes:

1 x 8-Pin Flat Dial Switch 2.54mm
