TT2222 NPN General Purpose Transistor (TO-92)

TT2222 NPN General Purpose Transistor (TO-92)

SpecificationDetails
Transistor PolarityNPN
Package TypeTO-92
Collector-Emitter Voltage ($V_{CEO}$)30V - 40V
Collector-Base Voltage ($V_{CBO}$)60V
Collector Current ($I_C$) Continuous600mA - 800mA
DC Current Gain ($h_{FE}$)100 to 300
Transition Frequency ($f_T$)250 MHz - 300 MHz
Total Power Dissipation ($P_{tot}$)625 mW
                                 Price

🚚 Ships within 24 Hours
📦 Pan India Delivery
₹ 33.90 ₹ 33.90
(Tax included)

Barcode: 65834

Product Description

The TT2222 Transistor is engineered for versatility in low-power electronic design. As an NPN device, it is typically used as a "low-side switch," where a small base current controls a much larger current flowing from the collector to the emitter. Its high transition frequency ($f_T$) makes it suitable for high-speed switching and VHF (Very High Frequency) amplification. The TO-92 package is breadboard-friendly and ideal for through-hole PCB assembly, making it a favorite for students, hobbyists, and industrial prototyping.

Key Features

  • High Switching Speed: Capable of handling high-frequency signals up to 300 MHz.

  • Moderate Current Handling: Can drive loads up to 600mA, sufficient for most relays and small DC motors.

  • Low Saturation Voltage: Minimizes power loss and heat generation when used as a switch.

  • Wide Gain Range: Provides consistent amplification across a variety of input signal levels.

  • Compact Footprint: The small TO-92 package saves valuable space on dense circuit boards.

Technical Details

  • Pinout (Facing Flat Side): 1. Emitter, 2. Base, 3. Collector.

  • Material: Silicon-based semiconductor.

  • Operating Temperature: -55°C to +150°C.

Prototyping and Engineering Tips from Robogears

  • The "Base Resistor" Rule: Never connect the base of a TT2222 directly to a microcontroller pin (like Arduino's 5V). Always use a current-limiting resistor (typically $1k\Omega$ to $10k\Omega$) to protect both the transistor and the MCU from excessive current.

  • Driving Inductive Loads: When using the TT2222 to switch a relay or a DC motor, always place a "Flyback Diode" (like 1N4007) in parallel with the load (cathode to $V+$). This prevents the back-EMF spike from destroying the transistor when it turns off.

  • Thermal Management: If you are running the transistor near its $600mA$ limit, the TO-92 package will get hot. Ensure adequate airflow or consider using the TO-220 version (like TIP122) if you need higher current handling without a heatsink.

Package Includes

  • 1 x TT2222 NPN Bipolar Junction Transistor (TO-92)

Disclaimer

Ensure correct pin orientation before soldering; reversing the Emitter and Collector can lead to circuit failure or component damage. Always verify the $V_{CEO}$ rating against your power supply voltage to prevent breakdown.

🔒
