DT830D Digital Multimeter – Handheld Voltmeter, Ammeter, and Ohmmeter with Continuity Buzzer & Transistor (hFE) Tester for Electronics Repair and DIY

DT830D Digital Multimeter – Handheld Voltmeter, Ammeter, and Ohmmeter with Continuity Buzzer & Transistor (hFE) Tester for Electronics Repair and DIY

(0 review)
FeatureDetails
DC Voltage200mV to 1000V
AC Voltage200V to 750V
DC Current200$\mu$A to 10A
Resistance200$\Omega$ to 2000k$\Omega$
Special FunctionsContinuity Buzzer, Diode Test, hFE Tester
Display3.5 Digit LCD (Max 1999)
Price
₹ 169.49 ₹ 169.49
(Tax included)

Product Description The DT830D is an industry-standard, pocket-sized digital multimeter (DMM) that is essential for every electronics workbench. Whether you are a student, a DIY hobbyist, or a technician at Robogears Pvt Ltd, this meter provides a quick and accurate way to measure voltage, current, and resistance. Unlike the base 830B model, the DT830D features an integrated continuity buzzer, making it remarkably easier to troubleshoot PCB short circuits and cable breaks without needing to look at the screen. Its rugged yellow casing and compact form factor make it perfect for both field service and indoor lab environments.

Key Highlights

  • Instant Continuity Testing: The built-in audible buzzer provides immediate feedback for low-resistance connections, crucial for tracing circuit paths.


  • Transistor hFE Measurement: Includes a dedicated socket to measure the DC current gain of NPN and PNP transistors, allowing for quick component health checks.

  • High Voltage & Current: Capable of measuring up to 1000V DC and a dedicated 10A terminal for high-current circuit testing.


  • Square Wave Output: Features a 50Hz signal output (approx. 3V p-p), useful for simple audio and digital signal circuit testing.

  • Clear LCD Interface: A 3.5-digit high-contrast display ensures that readings are visible even in varied lighting conditions

Technical Specifications

  • DC Voltage Accuracy: $\pm$(0.5% + 2)

  • AC Voltage Accuracy: $\pm$(1.2% + 10)

  • Fuse Protection: 200mA/250V (Internal)

  • Operating Temperature: 0°C to 40°C

  • Dimensions: ~126mm x 70mm x 24mm

  • Weight: ~150g (including 9V 6F22 battery)

Prototyping & Installation Tip When measuring current above 200mA, move the red probe to the 10A jack. Safety Warning: The 10A circuit is usually unfused; to avoid internal damage, do not measure high current for more than 10 seconds at a time and allow at least 15 minutes between such measurements. For beginners, always start your voltage measurements at the highest range (1000V DC or 750V AC) and then turn the dial down for better precision once you know the approximate voltage.


[Image demonstrating a diode test and continuity check on a robotics controller board]

Note: This product includes 1 x DT830D Multimeter, 1 pair of Test Leads, and 1 x 9V Battery. Product images are for illustration purposes only.
