SW-420 Vibration and Shock Sensor Module for Arduino

SW-420 Vibration and Shock Sensor Module for Arduino

(0 review)
SpecificationDetails
Operating VoltageDC 3.3V – 5V
Sensor TypeSW-420 (Normally Closed)
Comparator ICLM393 High-Precision Voltage Comparator
Current Consumption~15mA
Output TypeDigital Switching (0 & 1)
AdjustmentOnboard Sensitivity Potentiometer
PCB Dimensions32mm x 14mm
Price
₹ 50.85 ₹ 50.85
(Tax included)

Product Description

The SW-420 Sensor Module utilizes a spring-based internal mechanism that provides a reliable digital trigger upon sensing a vibration. Unlike mercury-based switches, this sensor is non-directional and environmentally safe. The raw signal from the SW-420 element is processed by an onboard LM393 comparator, which provides a clean, noise-free TTL-compatible output (D0). The module features two onboard LEDs: a Power LED to confirm the DC supply and a Signal LED that toggles when a vibration is detected. Its small form factor and simple 3-pin interface make it perfect for integration into tight enclosures or hobbyist projects.

Key Features

  • Adjustable Sensitivity: Use the blue multi-turn potentiometer to set the vibration intensity required to trigger the output.

  • Normally Closed Design: The sensor is in a conductive state by default, providing high reliability for security applications.

  • LM393 Processing: Ensures a sharp digital pulse output that is easily readable by any microcontroller.

  • Low Power Requirement: Ideal for battery-operated IoT devices and portable alarms.

  • Easy Installation: Pre-drilled 3mm mounting hole for secure attachment to any vibrating surface.

Technical Details

  • Pinout: 1. VCC: 3.3V to 5V. 2. GND: Ground. 3. DO: Digital Output Signal.

  • Logic State: Output is LOW when still and HIGH when vibration is detected.

  • Durability: Rated for millions of vibration cycles under standard operating conditions.

Prototyping and Engineering Tips from Robogears

  • The "Window" of Detection: The SW-420 is excellent for detecting "sudden" impacts. If you are building a window alarm, mount the sensor directly to the glass frame. The vibration from a knock or a break will trigger the digital pin instantly.

  • Sensitivity Calibration: To calibrate, turn the potentiometer until the "Signal LED" just turns OFF. Now, even a light tap on the table should make the LED flicker. If it's too sensitive and triggers from a nearby fan, turn the potentiometer slightly in the opposite direction.

  • Interrupt Usage: In your Arduino code, connect the DO pin to an Interrupt pin (e.g., Pin 2 or 3 on an Uno). Use RISING or CHANGE mode in your attachInterrupt() function to catch the very first millisecond of a vibration, ensuring your alarm responds without delay.

Package Includes

  • 1 x SW-420 Vibration / Tilt Sensor Module

Disclaimer

This module is a digital switch and cannot measure the "magnitude" of vibration (G-force); for variable intensity data, an analog accelerometer is required. Ensure the module is mounted firmly, as a loose sensor will provide inconsistent and "chattery" data.
